Scrap Iron Tire Metal Shredder Crusher Machine Cans Double Shaft Shredding

Scrap Iron Tire Metal Shredder Crusher Machine Cans Double Shaft Shredding

Product Details:

Place of Origin: China
Brand Name: TONTEN
Model Number: TT-S800

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Small models are packed in wooden boxes, large models load in containers
Delivery Time: 5-8 work days
Payment Terms: T/T
Supply Ability: 30 sets per month
Get Best Price Contact Now

Detail Information

Power: 18.5x2kw Capability: 3-5t/h
Feed Size: 800x800mm Weight: 3200kg
Rotor Speed: 83rpm Rotor Diameter: 400mm
Rotor Blade Qty: 96pcs Reducer: Double

Product Description

Scrap Iron Tire Metal Shredder Crusher Machine Cans Double Shaft Shredding



Product introduction:
TONTEN Double shaft shredder machine is a kind of equipment that uses the relative movement between the blade rollers to tear, shear, cut and other comprehensive actions on the material to reduce the material to the required size. It has a better crushing effect when processing tough materials, flexible materials and ductile materials. The double-shaft shredder has two rotating shafts and is equipped with many rotating blades. When the material is put into the shredder, the blades will tear it into small pieces. Because the double-shaft shredder has two rotating shafts, it is able to provide higher shredding efficiency and more powerful processing capabilities. This means that the shredder can process large amounts of material faster and is suitable for processing harder and stronger materials.



Advantages:
1. Shredder machine motor uses a full copper core motor to reduce energy consumption and has a long service life.
2. The shredder gearbox is welded with steel plates, which has high precision, good contact, low noise and a long service life.
3. The transmission parts of the shredder are connected by couplings to reduce vibration, protect the main shaft and reducer, and do not lose force.
4. Double shaft shredder machine usually have a long service life because the load is distributed on two shafts, reducing the degree of wear on each shaft.
5. Double shaft shredder have two rotating shafts and run more smoothly.
6. Use couplings to reduce vibration, protect the main shaft and reducer, and do not lose force.
The shredder blades are forged, annealed, heat treated, tempered and heat-insulated, and finely ground by online cutting.



Working principle:
The main working parts of shredder pair of rollers rotating relative to each other, with spirally arranged gear teeth installed on the rollers. During operation, after the material enters the machine body, the double shafts begin to rotate rapidly, capturing the material on the cutting blades for crushing. After multiple tearing and compression,material reaches the ideal crushing effect. After entering the machine, the material is bitten and sheared by the staggered rotating gear teeth made of hard wear-resistant materials, and is split and shredded into pieces below the set size and forced out of the machine. The rollers are driven by motor through the reducer and have a large torque. When encountering difficult-to-crush objects, they will automatically reverse under the action of the PLC automatic control system,reverse forward and reverse multiple times until material shredded and discharged.



Shredder machine specifications:

Model
Motor
Capacity
Weight
800
18.5x2
3-5t/h
3200kg
1000
30x2
5-8t/h
7800kg
1600
75x2
12-18t/h
13600kg
