Hammer Crusher Pebble Concrete Hammer Crusher Machine Diesel Type

Hammer Crusher Pebble Concrete Hammer Crusher Machine Diesel Type

Product Details:

Place of Origin: China
Brand Name: TONTEN
Model Number: PC-240x450

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden box
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 20 units/month
Get Best Price Contact Now

Detail Information

Power: 7.5kw Capacity: 5-7t/h
Number Of Hammer: 16 Output Size: 0-25mm
Weight: 460kg Drive Mode: Diesel
Target: Pebble Concrete Item: Hammer Crusher Machine

Product Description

Hammer Crusher Pebble Concrete Hammer Crusher Machine Diesel Type



Product introduction:
Hammer crusher strikes and crushes materials with high-speed rotating hammer head. Hammer crusher is one of the main equipment for fine crushing of limestone, coal or other brittle materials with medium hardness or below in metallurgy, building materials, chemical industry and hydropower and other industrial sectors. It has the characteristics of large crushing ratio, high production capacity and uniform product particle size. Advanced structure, reliable performance, stable operation and low energy consumption.



Working principle:
The hammer crusher mainly includes rotor, hammer head, hammer frame, pin shaft, frame, crushing plate, screen plate and transmission parts. The hammer crusher mainly relies on impact energy to complete the material crushing operation. When the hammer crusher is working, the motor drives the rotor to rotate at high speed, and the material enters the crusher cavity evenly. The high-speed rotating hammer head impacts the material to be crushed. At the same time, the gravity of the material itself causes the material to rush from the high-speed rotating hammer head to the baffle and screen bar in the frame. The material larger than the screen hole size is retained on the screen plate and continues to be hit and ground by the hammer until it is crushed to the required discharge particle size and finally discharged from the machine through the screen plate.



Hammer crusher machine specification:

Model



Power

(kw)

Capacity

(t/h)

Feed size
(mm)

Number

of hammer

Weight

(t)

PC-200x300

5.5

3-4

210x250

9

0.23

PC-​240x250

7.5

5-7

270x310

16

0.6

PC-​310x520

15

7-10

300x380

20

0.8

PC-​400x600

22

10-20

440x390

20

1.2

PC-​600x600

30

20-30

590x330

24

1.5

PC-​600x800

55

18-32

650x460

24

1.9

PC-​800x800

75

25-35

650x480

28

2

PC-​800x1000

90

35-55

650x550

28

3.6

PC-​1000x1000

110

60-80

850x580

32

5
