Gold Mining Ball Mill Grinding Machine Ball Mill Price Limestone
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | BM-900x1800 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export wooden packing or in container |
| Delivery Time: | 7-10work days |
| Payment Terms: | T/T |
| Supply Ability: | 50 Sets per month |
|
Detail Information |
|||
| Shell Rotation Speed: | 36-38r/min | Ball Load: | 1.5t |
|---|---|---|---|
| Capacity: | 0.65-600t/h | Type: | Ball Mill |
| Name: | Ball Mill Grinding Machine | Other Name: | Ball Mill Price |
| Motor Type: | AC Motor | Color: | Customized |
Product Description
Gold Mining Ball Mill Grinding Machine Ball Mill Price Limestone
Ball mill grinding machine overview:
TONTEN machinery ball mills are widely used in manufacturing industries such as ore dressing process, paint, cement, silicate, new building materials, refractory materials, fertilizers, ferrous metals, non-ferrous metals and glass ceramics. As the balls fall from near the top of the shell, they are reduced in size by impact. The final stage of comminution is carried out in a tumbling mill using steel balls as the grinding media, hence the name ball mill.
Advantage:
1.TONTEN ball mill has a simple structure, and is mainly composed of a feeding part, a discharging part, a rotating part, and a transmission part reducer, a small transmission gear, a motor, and an electronic control. It is easy to install and debug, and simple to operate.
2.There are two grinding methods: dry and wet, choose according to the specific requirements of customers
3.The ball mill lining material can be changed and customized according to the specific requirements of customers.
4.Ball mill grinding machine can adapt to various materials, can produce continuously, has large production capacity, and can meet the needs of larger-scale production.
5.All kinds of materials can be processed, and the materials have good process performance after processing.
Ball mill grinding machine specification:
|
Model |
Shell rotation speed(r/min) |
Ball load (t) |
Feeding size (mm) |
Discharging size (mm) |
Capacity (t/h) |
Motor power (kw) |
Weight (t) |
|
BM-900x1800 |
36-38 |
1.5 |
< =20 |
0.075-0.89 |
0.65-2.5 |
18.5 |
3.85 |
|
BM-900x3000 |
36 |
2.7 |
< =20 |
0.075-0.89 |
1.1-3.5 |
22 |
4.6 |
|
BM-1200x2400 |
36 |
3 |
< =25 |
0.075-0.6 |
1.5-4.8 |
30 |
13.6 |
|
BM-1200x3000 |
36 |
3.5 |
< =25 |
0.074-0.4 |
1.6-5 |
37 |
14.3 |
|
BM-1200x4500 |
32.4 |
5 |
< =25 |
0.074-0.4 |
1.6-5.8 |
55 |
15.6 |
|
BM-1500x3000 |
29.7 |
7.5 |
< =25 |
0.074-0.4 |
2.0-5.0 |
75 |
19.5 |
|
BM-1500x4500 |
27 |
11 |
< =25 |
0.074-0.4 |
3.0-6.0 |
110 |
21 |
|
BM-1500x5700 |
28 |
12 |
< =25 |
0.074-0.4 |
3.5-6 |
130 |
24.7 |
|
BM-1830x3000 |
25.4 |
11 |
< =25 |
0.074-0.4 |
4.0-10.0 |
130 |
28 |
Ball mill workshop:
