Slag Cement Ball Mill Machine Grinding Ball Mill Fine Powder For Mining
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | BM-1500x4500 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export wooden packing or in container |
| Delivery Time: | 7-10work days |
| Payment Terms: | T/T |
| Supply Ability: | 50 Sets per month |
|
Detail Information |
|||
| Capacity: | 3-6t/h | Power: | 110kw |
|---|---|---|---|
| Simplified Speed: | 27r/min | Ball Load: | 11t |
| Feeding Size: | ≤25mm | Finished Size: | 0.74-0.4mm |
| Weight: | 22.1t | Name: | Ball Mill Machine Grinding Ball Mill Fine Powder |
Product Description
Slag Cement Ball Mill Machine Grinding Ball Mill Fine Powder For Mining
Introduction for ball mill:
TONTEN machinery grinding ball mill consists of the feeding part, discharging part, rotating part, transmission part and other main parts. The hollow shaft is made of cast steel, the inner lining is removable, the rotating gear is made of cast gear hobbing, and the cylinder is inlaid with wear-resistant lining, which has good wear resistance. According to the material and the discharge method, dry ball mill and wet grid ball mill can be selected. The working principle of the ball mill is to grind the material into the required fine powder through friction and impact. The ball mill is mainly used in non-ferrous metals, ore dressing, ceramics, chemicals, cement, glass, refractory materials, fertilizers and other industries. The ball mill is divided into dry and wet types. The dry type is used in refractory materials, cement, fertilizers, and glass industries; the wet type is used in ore dressing, ceramics, and chemical industries.
Main features of ball mill:
1. High production efficiency: small unit equipment footprint and strong production capacity. Can work continuously with high production efficiency
2. Controllable discharging particle size: products of different particle sizes can be obtained by adjusting parameters such as rotation speed, ball-to-material ratio, overflow time, etc. Meet different fineness requirements.
3. Simple structure: The ball mill consists of three parts: the body, grinding balls and drive device. It has a compact structure and is easy to maintain.
4.Suitable for grinding materials of different properties such as hardness, brittleness, wetness, etc. It can be used in chemical, metallurgical, building materials and other industries.
Parameters:
| Model |
Cylinder speed |
Ball load weight(t) | Feeding size(mm) | Discharging size(mm) | Capacity(t/h) | Power(kw) | Weght(t) | ||||
| BM900x1800 | 36-38 | 1.5 |
≤20 |
0.075-0.89 | 0.65-2.5 | 18.5 | 5.8 | ||||
| BM900x3000 | 36 | 2.7 | ≤20 | 0.075-0.89 | 1.1-3.5 | 22 | 6.95 | ||||
| BM1200x2400 | 36 | 3 | ≤25 | 0.075-0.6 | 1.5-4.8 | 30 | 13.56 | ||||
| BM1200x3000 | 36 | 3.5 | ≤25 | 0.074-0.4 | 1.6-5 | 37 | 14.31 | ||||
| BM1200x4500 | 32.4 | 5.2 | ≤25 | 0.074-0.4 | 1.6-5.8 | 55 | 15.6 | ||||
| BM1500x3000 | 29.7 | 7.5 | ≤25 | 0.074-0.4 | 2-5 | 75 | 19.5 | ||||
| BM1500x4500 | 27 | 11 | ≤25 | 0.074-0.4 | 3-6 | 110 |
22.1 |
||||
| BM1500x5700 | 28 | 12 | ≤25 | 0.074-0.4 | 3.5-6 | 130 | 25.8 | ||||
| BM1830x3000 | 25.4 | 11 | ≤25 | 0.074-0.4 | 4-10 | 130 | 34.5 | ||||
| BM1830x4500 | 25.4 | 15 | ≤25 | 0.074-0.4 | 4.5-12 | 155 | 38 | ||||
| BM1830x6400 | 24.1 | 21 | ≤25 | 0.074-0.4 | 6.5-15 | 210 | 43 | ||||
| BM1830x7000 | 24.1 | 23 | ≤25 | 0.074-0.4 | 7.5-17 | 245 | 43.8 | ||||
| BM2100x3000 | 23.7 | 15 | ≤25 | 0.074-0.4 | 6.5-36 | 155 | 45 | ||||
Ball mill:
