Double Rotor Two Stage Crusher Rock Limestone Coal Machine For Sale
Product Details:
Place of Origin: | China |
Brand Name: | TONTEN |
Model Number: | TT-DH1000x800 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 Set |
---|---|
Price: | Negotiable |
Packaging Details: | standard international export packing, container or as required |
Delivery Time: | 5-7 working days |
Payment Terms: | T/T |
Supply Ability: | 50 Sets per month |
Detail Information |
|||
Feeding Size: | 180mm | Discharge Size: | ≤3mm (bellow 2mm 85%) |
---|---|---|---|
Output: | 70-80t/h | Moisture Content: | 20% |
Motor Power: | 75+55kw | Size: | 4100x1860x2550mm |
Use: | Rock Limestone Coal | Type: | Two Stage Crusher Machine |
Product Description
Double Rotor Two Stage Crusher Rock Limestone Coal Machine For Sale
Introduction to double-stage crusher machine:
TONTEN machinery double stage crusher machine is also called double-stage non-screen bottom crusher. Double-stage crusher machine is equivalent to two hammer crushers combined into one, which is reasonably combined into a whole. Two sets of rotors are used in series. The traditional crusher with grate screen plate and the two-stage screenless crusher have made a greater breakthrough in the fineness of the discharge, and there is no requirement for the crushing of materials with high water content. The two-stage screenless crusher can crush common materials such as shale, coal slag, coal gangue, construction waste, limestone, river pebbles, potassium feldspar, talc, marble, dolomite, fluorite, lime, activated clay, activated carbon, bentonite, iron ore, calcite, kaolin, cement, phosphate rock, gypsum, glass, manganese ore, titanium ore, copper ore, chromium ore, refractory materials, thermal insulation materials, coal coke, coal powder, carbon black, clay, bone meal, titanium dioxide, iron oxide, and other high-humidity and high-hardness materials and more than 300 kinds of materials in the construction industry. It is mainly aimed at the construction industry and brick factories and has a very good crushing effect.
Advantages of two stage crusher machine:
1. Unique shift gap technology, the hammer head does not need to be repaired after wear, and can be moved and used repeatedly.
2. The crusher rotates in both directions, and through continuous equal-frequency bidirectional operation, the hammer head and crushing tooth plate wear evenly, thereby reducing the frequency of replacing wearing parts.
Specification:
Model |
Feeding size |
Discharge size |
Capacity |
Motor power |
Size (mm) |
TT-DH600x400 |
100 |
≤3mm |
10-15t/h |
18.5 +15 kw |
2450x1200x1580 |
TT-DH600x600 |
110 |
20-25t/h |
22 +18.5 kw |
3100x1300x1800 |
|
TT-DH800x600 |
120 |
40-50t/h |
45 +37 kw |
3200x1420x2100 |
|
TT-DH800x800 |
120 |
45-60t/h |
45 +37 kw |
3410x1600x2200 |
|
TT-DH1000x800 |
120 |
50-60t/h |
45 +45 kw |
3750x1700x2300 |
|
TT-DH1000x1200 |
120 |
50-70t/h |
55 +45 kw |
3980x1900x2600 |
|
TT-DH1000x1400 |
180 |
70-80t/h |
75+55 kw |
4100x2100x2750 |
|
TT-DH1200c1000 |
180 |
80-100t/h |
90 +55 kw |
4600x2500x3100 |
|
TT-DH1400c1200 |
200 |
100-120t/h |
160 +132 kw |
5800x2700x3160 |
