Automatic Vibrating Stone Screening Machine Rock Separator Screen Crusher

Automatic Vibrating Stone Screening Machine Rock Separator Screen Crusher

Product Details:

Place of Origin: China
Brand Name: TONTEN
Model Number: TTS-1650

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: standard international export packing, container or as required
Delivery Time: 5-7 working days
Payment Terms: T/T
Supply Ability: 50 Sets per month
Get Best Price Contact Now

Detail Information

Motor Power: 75-90kw Shaft Clearance: 25-100mm
Shaft Number: 14-18 Pcs Input Size: ≤40mm
Capacity: 300-800t/h G.Weight: 28ton
Material: Soil Mudstone Rock Type: Separator Screening Machine
Highlight:

Vibrating stone screening machine

,

stone screening machine Crusher

,

Automatic vibrating screen stone crusher

Product Description

Soil Mudstone Rock Separator Screening Machine Automatic Separator



Product introduction:
The mud-stone separator is mechanical device for separating mud and stone,to efficiently separate different components, thereby improving the utilization rate and environmental protection of the material. Mainly used for mud, stone, limestone,coal gangue, shale, gravel, earth and stone, river pebbles,sand, slag, etc.



Working principle of mud rock separator:
Separator uses mechanical principles of gravity, inertia and vibration inside the equipment to separate the soil and stones. Specifically, the net inside the equipment will vibrate continuously, causing the soil and stones in raw materials to collide and rub continuously. Due to different densities and weights of soil and stones,soil and stones will gradually separate under action of vibration.Collection trough is set under net to collect the separated soil and stones separately,vibration generated by the vibrator is used to make the materials jump on the screen, thereby realizing the separation and screening of materials. When materials pass through the screen, large pieces of materials and small particles of materials will fall into different areas respectively, thereby realizing the grading and screening of materials.



Automatic Vibrating Stone Screening Machine Rock Separator Screen Crusher 0



Specification:

Model

Power

(kw)

Shaft clearance (mm)

Shaft number (pcs)

Input size (mm)

Capacity

(ton/h)

TTS-0816

7.5-11

10-50

6-8

≤20

30-100

TTS-1020

11-15

10-50

7-10

≤25

60-180

TTS-1230

18.5-30

15-70

8-11

≤30

100-300

TTS-1235

22-37

20-80

10-13

≤30

130-350

TTS-1340

37-45

20-90

11-14

≤33

150-500

TTS-1445

45-55

25-100

12-15

≤35

180-600

TTS-1550

55-75

25-100

13-17

≤38

200-800

TTS-1655

75-90

30-100

14-18

≤40

250-900

TTS-1860

75-100

30-100

15-20

≤50

350-1000



Automatic Vibrating Stone Screening Machine Rock Separator Screen Crusher 1Automatic Vibrating Stone Screening Machine Rock Separator Screen Crusher 2
