Metallurgy Hydraulic Metal Shear Machine Gantry Sheet Cutting 1000ton

Metallurgy Hydraulic Metal Shear Machine Gantry Sheet Cutting 1000ton

Product Details:

Place of Origin: China
Brand Name: TONTEN
Model Number: TT-G1000

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: export packing, container or as required
Delivery Time: 5-8 work days
Payment Terms: T/T
Supply Ability: 50 Sets per month
Get Best Price Contact Now

Detail Information

Max.cutting Force: 1000ton Max.cutting Width: ≤3000mm
Shear Efficiency: 3-5t/min Motor Power: 5x45kw
Voltage Supply: 220/380v Operation Method: Automatic
Cutting Raw Materials: Metal Machine Type: Hydraulic Gantry Shear Machine Metal Cutting
Highlight:

Metallurgy hydraulic metal shear machine

,

1000ton hydraulic metal shear machine

,

Metallurgy hydraulic sheet cutting machine

Product Description

Metallurgy Hydraulic Gantry Shear Machine Metal Cutting Manufacturer

Introduction for gantry shears:
TONTEN machinery gantry shears machine consist of shear body, a workbench, a fixture and an electronic control system. Is large-scale metal material cutting equipment and is widely used in automobile manufacturing, shipbuilding enterprises, steel processing, energy, construction sites, scrap metal recycling and other fields. It has hydraulic and electrical integrated control and can implement single and continuous action conversion. The shear knife is a parallel knife beam composed of two rigid blades. When it is driven into the working position by the oil cylinder, the cutting action is completed to achieve the purpose of high-concentration one-time removal of the material. The rotation of the motor drives the oil pump to work, extract the hydraulic oil in the oil tank, transport it through the hydraulic oil pipe, and transmit it to each hydraulic cylinder, driving the piston rod of the cylinder to move horizontally to shear waste of various sizes. It adopts hydraulic drive, reliable safety performance and easy operation


Features:
1. The gantry shear uses precise tool parts, advanced hydraulic system and electronic control system, which can ensure extremely high accuracy and stability during shearing, thus meeting the processing requirements of various production fields with high precision requirements.
2. A variety of operation modes are available for customers to choose and customize, with centralized buttons, manual, semi-automatic and automatic operations
3. The gantry shear has strong shearing ability and efficient operating performance. The workbench area is large and the steel plate thickness is thicker, which can complete more complex, larger and heavier shearing tasks.


Gantry shear specification:

Model

Max.cutting force(ton)

Max.cutting width(mm)

Motor Power(kw)

TT-G200

200

≤1400

2x35

TT-G300

300

≤1500

2x37

TT-G500

500

≤1600

2x37

TT-G630

630

≤1800

3x42

TT-G800

800

≤1800

4x45

TT-G1000

1000

 ≤2000

5x45

TT-G1200

1200

≤2800

5x50

TT-G1500

1500

≤3000

6x90

TT-G1800

1800

≤3200

6x90


Customer site:
Metallurgy Hydraulic Metal Shear Machine Gantry Sheet Cutting 1000ton 0

Metallurgy Hydraulic Metal Shear Machine Gantry Sheet Cutting 1000ton 1Metallurgy Hydraulic Metal Shear Machine Gantry Sheet Cutting 1000ton 2
