Box Hammer Crusher Granite Quartz Gravel Basalt Limestone Box Crusher Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | TT-BC700x1000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export standard wooden box packaging or container |
| Delivery Time: | 7-10 work days |
| Payment Terms: | T/T |
| Supply Ability: | 30 Sets per month |
|
Detail Information |
|||
| Power: | 45-55kw | Capacity: | 50-80t/h |
|---|---|---|---|
| Roll Diameter: | 700mm | Roll Length: | 1000mm |
| Feeding Granularity: | ≤1200mm | For Stone: | 300mpa |
| Name: | Box Hammer Crusher | Used For: | Crusher Granite Quartz Gravel Basalt Limestone |
| Highlight: | Granite Box Hammer Crusher,Quartz Box Hammer Crusher,Basalt Box Hammer Crusher |
||
Product Description
Box Hammer Crusher Granite Quartz Gravel Basalt Limestone Box Crusher Machine
Product Introduction:
Box-type hammer crusher machine equipment is a kind of crushing equipment widely used in mining, metallurgy, building materials and chemical industries. TONTEN Machinery box crusher machine suitable for crushing various brittle materials such as granite, quartz, gravel, basalt and limestone. Box-type crusher can achieve large-scale material crushing, reduce subsequent processing costs, compact design, easy maintenance and replacement of parts. High working efficiency, suitable for large-scale production.The service life of the hammer head is increased by 4-6 times, and each pair of hammer heads can crush 30,000-40,000 tons of stone, which has achieved a breakthrough in crushing technology and truly achieved twice the result with half the effort.Box-type hammer crusher is widely used in mining, metallurgy, building materials and other fields because of its simple structure, easy operation, and ability to efficiently process a variety of brittle materials.
Compared with other crushers, the crusher has lower energy consumption. Box-type hammer crusher uses high-speed rotating hammer to impact and crush the material. After the material enters the crushing chamber, the hammer hits the material at high speed to crush it. The crushed material is discharged through the screen plate to reach the required particle size.
Applicable Materials:
Granite:high hardness, high compressive strength, commonly used in building materials and road engineering.
Quartz: high hardness, strong wear resistance, widely used in glass, ceramics and other industries.
Gravel: mainly used as concrete aggregate and road foundation material.
Cement Clinker: TONTEN Machinery box hammer crushers machine are used for raw material processing in the cement industry.
Basalt: high hardness, high compressive strength, suitable for construction and highway engineering.
Limestone: Commonly used in cement production, construction and chemical industries.
Bauxite: Commonly used for the crushing of bauxite.
Ore: Suitable for the initial crushing of various metal and non-metal ores.
Box Crusher Parameter:
|
Model |
TT-1000x1000 |
TT-1200x1200 |
TT-1400x1400 |
TT-1600x1600 |
TT-1800x1800 |
|
Diameter of roll(mm) |
1000 |
1200 |
1400 |
1600 |
1800 |
|
Length of roll(mm) |
1000 |
1200 |
1400 |
1600 |
1800 |
|
Capacity(ton/hour) |
90-120 |
130-160 |
190-210 |
250-300 |
300-400 |
|
Feed size(mm) |
≤800 |
≤900 |
≤1000 |
≤1000 |
≤1200 |
|
Power(kw) |
75-90 |
90-132 |
132-160 |
160-220 |
280-315 |
