Mobile Box Crusher Station Tire Crushing Stone Line Box Hammer Crusher
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | 600*600 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 5000$ |
| Packaging Details: | Export standard wooden box packaging or container |
| Delivery Time: | 10-20 work days |
| Payment Terms: | T/T |
| Supply Ability: | 20 sets per month |
|
Detail Information |
|||
| Product Name: | Box Crusher | The Machines Classification: | Crushing Equipment |
|---|---|---|---|
| After-sales Service Provided: | Video Technical Support | Processed Materials: | Ore Stone Mining |
| Quality: | High-Quality | Color: | Customer Requirement |
| Factory Visit: | Warmly Welcomed | Max Feeding Size: | 0-1000mm |
| Model: | 600*600 | MOQ: | 1 |
| Highlight: | Stone Line Box Hammer Crusher,Mobile Box Hammer Crusher |
||
Product Description
Top Sale Mobile Box Crusher Station Tire Crusher Stone Line Box Hammer Crusher
Introduction:
The box crusher is a stone breaking machine that integrates the advantages of jaw crusher, hammer crusher, impact crusher, snail crusher and other advanced technologies at home and abroad. The large stone blocks are directly broken and automatically fed. The materials with a side length of 450-1200 mm are directly broken into powder to 80 mm ore without blocking and jamming. It can also be used as secondary crushing. This product is mainly used in mines, cement, building materials Chemical industry and other industries.
Feature:
1. Large feed particle size, large crushing ratio and uniform discharge.
2. The finished product rate is high, and the granular product accounts for about 85%, which fully meets the use requirements.
3. The hammer shaft of the box crusher is adjustable, and the hammer head has a long service life.
4. Adjustable grid size, controllable particle size and good particle shape.
5. The case of the box crusher can be turned over, which makes maintenance more convenient.
6. Square handle bolt, impact and wear resistant.
7. High output and stable performance.
8. The coarse and medium crushing are in place in one step, and the process flow is simplified.
9. The hammer head, grate plate and counterattack plate made of high wear-resistant materials have a longer service life.
10. Small supporting power, low energy consumption, simple maintenance and few vulnerable parts.
Paramenters:
| Model | 800*800 | 1000*1000 | 1200*1200 | 1400*1400 | 1600*1600 |
| Roller Diameter | 800 | 1000 | 1200 | 1400 | 1600 |
| Roller Length | 800 | 1000 | 1200 | 1400 | 1600 |
| Yield | 70-100 | 90-120 | 130-160 | 190-210 | 250-300 |
| Feed Particle size | ≤600 | ≤800 | ≤900 | ≤1000 | ≤800 |
| Power | 55-75 | 75-90 | 90-132 | 132-160 | 160-220 |
Application:
It is suitable for the first and second level crushing of various materials with compressive strength below medium and high hardness, especially for the crushing of materials used in mining, building materials, chemical and metallurgical industries.
Working Principle:
The stones fall directly into the high-speed rotating turntable from the upper part of the machine. Under the action of high-speed centrifugal force, high-speed impact and high-density crushing will occur. After the stones hit each other, eddy current motion will be formed between the turntable and the casing, resulting in many times of mutual impact, friction and crushing until the stones are crushed to the required particle size.
Customer:
Our machinery have been widely used in various industries, including mining,recycling,construction material and cement manufacture, chemical industry, electricity, metallurgy, mine, etc., enjoying a good reputation among customers both in the overseas and domestic market. TONTEN Machinery Limited Strictly control the mass production quality and lead time , and let the business goes smoothly !Our Customer Concept: Create Value for Customers is the only Reason for Our Existence.
Company Profile:
TONTEN machinery limited always adheres to the service concept of "customer first" and provides customers with a full range of high-quality services. TONTEN has established professional production, R&D and sales departments to serve customers. Future development goals: Comprehensive intelligent manufacturing, realizing automation, informatization and intelligence of the entire production process, improving production efficiency, product quality and resource utilization Providing personalized customization and flexibly adjusting production according to customer needs. R&D team: Committed to continuously optimizing product performance and improving product core competitiveness. Developed a series of stable, reliable and comprehensive mechanical equipment. At the same time, the team closely follows the development of cutting-edge technologies in the industry, continuously carries out product technology research, and injects a steady stream of innovative power into the company. Production team: Strictly abide by the quality management system, implement refined control throughout the production process, and ensure stable and reliable product quality. At the same time, the team is good at using lean production concepts, optimizing production processes, improving resource utilization efficiency, and ensuring that products can be delivered on time and with high quality. After-sales service team: Committed to providing customers with all-round caring support, regularly going to customers' sites for preventive maintenance, in addition, the team also provides customers with technical support services such as operation training and process optimization to ensure the stable operation of customer equipment in all aspects.
