Lime Vertical Kiln Vertical Shaft Cement Bauxite Vertical Kiln
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | TT-K400 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | Standard export containers,motors and small parts are packed in wooden cases |
| Payment Terms: | T/T |
| Supply Ability: | 10 Sets per month |
|
Detail Information |
|||
| Product Name: | Vertical Kiln | Capacity: | 200-400t/day |
|---|---|---|---|
| Kiln Inner Diameter: | 6600mm | Kiln Outer Diameter: | 8600mm |
| Kiln Height: | 38m | Type: | Vertical Kiln |
| Fuel: | Coal Powder, Natural Gas, Coal Gas | Calcining Temperature: | 300-1000℃ |
Product Description
Lime Vertical Kiln Vertical Shaft Cement Bauxite Vertical Kiln
Product Description:
Vertical kiln refers to thermal equipment that continuously calcines clinker with upper feeding and lower discharging. Composed of kiln body, feeding and discharging device, and ventilation equipment, etc. Widely used for calcining various refractory raw materials and lime, its advantages are lower infrastructure investment, less land occupation, high maturation efficiency, low fuel consumption, and easy mechanization and automation.
The use of a material sealing device allows for uninterrupted air flow during discharge, creating conditions for achieving automated operation of the entire kiln system. The utilization coefficient has also significantly increased.
Operational principle:
Vertical kiln according to the principle of countercurrent heat transfer. The materials inside the kiln move from top to bottom, and the smoke passes through the entire material column from bottom to top. The materials are preheated, calcined, and cooled inside the kiln
The working system includes a feeding and discharging system, a combustion system, an open air system, and a smoke exhaust system. The working system of the artificial vertical kiln is relatively simple. The raw materials and coke (or smokeless medium) are manually layered and fed into the kiln from the kiln, and heated by the flue gas from the lower part. As the material moves downwards, coke burns in the gaps between the raw materials. The combustion air is fed into the kiln by the blowing system from the bottom of the kiln (bottom air) or the periphery of the cooling belt (waist air), or both at the same time. The exhaust gas is discharged into the atmosphere through the chimney on the roof.
Vertical kiln advantage:
1.Production capacity range. TONTEN vertical kiln can produce burnt lime from 100 to 500 tons per day. Customers can choose the fit one according to their needs.
Compacted sizes,Wide range of raw material sizes.High heat utilization efficiency.
2.Use of alternative fuels. TONTEN machinery limited vertical kiln have many fuel options, such as oil, natural gas, coal and so on
3.Easy to control. Vertical shaft kiln controlled by PLC systems, so that you can monitor the whole calcining process and make easy adjustments.
Specification:
| Parameters | Daily 200Ton | Daily 300Ton | Daily 400Ton |
| Annual | 60000T | 90000T | 120000T |
| Annual working days | 300 day | 300 day | 300day |
| Kiln inner diameter | 5600mm | 6000mm | 6600mm |
| Kiln outer diameter | 7600mm | 8000mm | 8600mm |
| Kiln height | 33m | 35m | 38m |
Why choose us:
1. TONTEN can provide a custom-design solution to cement manufacturing for every client.
2. TONTEN provide perfect after-sales service, which covers equipment installation, operation, production, and maintenance. And we will send technicians for guidance and training until customers are satisfied.
3. All types of cement,Lime, bauxite and pyroxene are possible.
