Electric Chili Vegetables Fruit Fish Timber Drying Machine Industrial 8P
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | TT-8P |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Packaging Details: | load in container |
| Delivery Time: | 7-10work days |
| Payment Terms: | T/T |
| Supply Ability: | 30 Sets per month |
|
Detail Information |
|||
| Product Name: | Heat Pump Dryer Machine | Air Energy: | 8P |
|---|---|---|---|
| Applications: | Fruits, Vegetables, Medicinal Materials, Meat, Flowers, Mosquito Coils, Bamboo, Seafood, Wood | Technology: | Free Technology Support |
| Energy: | Energy Saving | Warranty: | 2 Year |
| Usage: | Drying Wet Materials | Feature: | High Efficiency Low Cost |
| Highlight: | Electric timber drying machine,8P timber drying machine,8P fruit drying machine industrial |
||
Product Description
Chili Vegetables Fruit Dryer Electric Fish Corn Heat Pump Dryer
Product Description:
Heat pump dryer is a device that uses heat pump technology for drying. It is mainly used in the drying and dehydration process of food, medicinal materials, wood, agricultural and sideline products, industrial products, etc.
Working Principle:
The heat pump dryer uses heat pump technology to transfer heat from the external low-temperature environment to the drying room through the thermal cycle process. It is mainly composed of fin evaporator (outside unit), compressor, fin condenser (inside unit) and expansion valve. The working fluid circulates in the system to complete the processes of evaporation, compression, condensation and throttling, thereby realizing heat transfer and heating of dry materials.
Features:
1. Low-temperature air closed-cycle drying: The heat pump dryer can realize low-temperature air closed-cycle drying, so that the temperature of the hot dry air in the drying room is between 20 and 80°C, meeting the high-quality drying requirements of most heat-sensitive materials.
2. Recyclable and useful volatile components: During the drying process, volatile components and moisture vaporize together into the air. When cooled by the condenser, the volatile components are liquefied, and useful volatile components can be collected and separated.
3. High efficiency and energy saving: The heat pump dryer uses the heat in the warm and humid air discharged from the drying chamber for heating. It only needs to input the power consumption of the heat pump compressor. It has high energy utilization efficiency and significant energy saving effect.
4. Convenient temperature and humidity control: The temperature of the working fluid in the evaporator and condenser can be adjusted to meet the temperature and humidity requirements of the material and ensure the drying effect and material quality.
5. Environmentally friendly: The drying medium in the heat pump dryer has a closed cycle, which avoids environmental pollution from material dust.
Advantage:
1. High efficiency and energy saving: The heat pump dryer has high energy utilization efficiency and is more energy-saving than the traditional convection dryer.
2. Good drying quality: Low-temperature air closed cycle drying can meet the high-quality drying requirements of most heat-sensitive materials.
3. Convenient temperature and humidity control: The temperature and humidity can be flexibly adjusted according to the requirements of the materials to ensure the drying effect and material quality.
4. Environmentally friendly: The drying medium has a closed cycle, which avoids environmental pollution from material dust.
Application:
- Food industry: drying of seafood, vegetables, fruits, meat products, etc.
- Agricultural field: drying of seeds, dried fruits, vegetables, etc.
- Industrial field: drying of paper products, wood, hardware products, chemical products, etc.
Specification:
| Model |
L*W*H |
Air energy | Fan | Yield(kg) |
| 2 cars | 3.7*2.5*2.2 | 3P | 3 sets | 600 |
| 4 cars | 4.9*2.5*2.2 | 6P | 4 sets | 1200 |
| 6 cars | 6.7*2.5*2.2 | 8P | 6 sets | 1800 |
| 8 cars | 5.7*3.5*2.4 | 10P | 8 sets | 2400 |
| 10 cars | 6.7*3.5*2.4 | 12P | 8 sets | 3000 |
| 12 cars | 7.7*3.5*2.4 | 15P | 12 sets | 3600 |
| 18 cars | 10.7*3.5*2.4 | 25P | 12 sets | 5400 |
| 24 cars | 9.7*5.0*2.4 | 30P | 16 sets | 7200 |
