Copper Wire Granulator Copper Rice Separator Cable Recycling Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | TT-800 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Small model export wooden packaging, large model load in full container |
| Delivery Time: | 5-7 working days |
| Payment Terms: | T/T |
| Supply Ability: | 30 Sets/Month |
|
Detail Information |
|||
| Capacity: | 300-600kg/h | Host Power: | 45kw |
|---|---|---|---|
| Sorting Power: | 5.2kw | Dust Removal Power: | 4.5kw |
| Total Power: | 57Kw | Cutterhead Material: | 9Crsi |
| Number Of Cutterheads: | 14 | Application: | Scrap Cable Recycling,Copper Wire Recycling |
Product Description
Copper Wire Granulator Copper Rice Separator Cable Recycling Machine
Product Description:
The copper wire recycling granulator is a device specially used to recycle waste copper wires and cables. It can process waste copper wires and cables into granular copper materials for reuse.
Describe:
The copper wire recycling granulator is composed of a feeding system, a crushing system, a separation system, a granulation system and a control system. It can crush, separate and granulate waste copper wires and cables, converting copper materials into granules to facilitate subsequent processing and reuse.
Introduce:
The copper wire recycling granulator uses mechanical methods to process discarded copper wires and cables, avoiding environmental pollution caused by traditional incineration or chemical treatment methods. It can efficiently decompose waste copper wires and cables into copper particles and separate them from insulating materials to realize the recycling of waste copper.
Features:
1. Energy saving and environmental protection: It is processed using mechanical and physical methods, without secondary pollution, and meets environmental protection requirements.
2. Automated operation: The equipment adopts an automated control system to simplify the operating process and reduce labor costs.
3. Efficient processing: The copper wire recycling granulator can efficiently process a large number of discarded copper wires and cables, improving recycling efficiency.
4. Versatility: Can adapt to various specifications and types of copper wires and cables for recycling.
Working principle:
1. Feeding and crushing: The waste copper wires and cables are fed into the crushing system through the feeding system, and after crushing treatment, they are broken down into smaller particles.
2. Separation and screening: The crushed copper particles are separated from the insulating material. Physical separation methods such as vibration screening, air flow separation, etc. can be used.
3. Granulation: The separated pure copper particles are granulated and made into granules through specific granulation equipment.
4. Control and collection: The entire process is automatically controlled through the control system, and the granulated copper particles are collected, packaged or further processed and utilized.
Specification:
|
Model |
capacity(kg/h) |
power(kw) |
Dimensions(mm) |
Weight(kg) |
|
400 |
300-400 |
15 |
1800*1300*1700 |
2850 |
|
600 |
500-600 |
37 |
2800*1800*2100 |
4200 |
|
800 |
700-800 |
45 |
2800*2000*2100 |
7600 |
|
1000 |
800-1000 |
55 |
2800*2500*2100 |
13500 |
