Household Waste Sorting Recycling Equipment Food Waste Recycling Plant
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | TT-DH2080 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Export wooden packing or in container |
| Delivery Time: | 15-20 work days |
| Payment Terms: | T/T |
| Supply Ability: | 30 Sets per month |
|
Detail Information |
|||
| Capacity: | 500-600t/day | Plant Power: | 285kw |
|---|---|---|---|
| Land Space: | 2600㎡ | Workers Required: | 5 |
| Material: | Client's Request | Type: | Household Waste Sorting Recycling Equipment |
| Color: | Requirement | Usage: | Waste Recycling |
Product Description
Household Waste Sorting Recycling Equipment Food Waste Recycling Plant
Working flow chart of household waste sorting recycling:
Food waste,Municipal solid waste, household waste, stale waste chain plate conveyor→trommel screen (Mesh size can be customized based on customer’s request. It is for organic waste or non-organic waste) → Magnetic separator(sorting metal) →Air separator(light materials and heavy materials)→Manual sorting platform(To sort different garbage, like, waste plastic, waste paper, waste can, etc...)→Baler machine (To pack recycled waste paper or plastic).
Introduction to main equipment:
Drum screen: Mainly used in the field of urban domestic waste sorting, it can effectively screen hard materials and inert materials of different sizes and specific gravity in mixed solid waste. During use, the drum sorting screen runs slowly and evenly, with small impact vibration, stable operation, simple installation, and can be placed directly on a flat ground or floor and under a silo. The machine is easy to seal and collect dust, has small maintenance, simple maintenance, and long service life.
Wind separator: Mainly suitable for urban and rural domestic waste sorting. The wind separator is a device that uses aerodynamic principles to classify materials. The equipment mainly separates materials of different densities in the garbage according to their weight to achieve the purpose of classification, recycling and reuse. The wind separator equipment has the characteristics of low power, low noise, large processing capacity, and high degree of automation. It can be widely used in large-scale treatment of large, medium and small garbage treatment plants.
Magnetic separator: It mainly relies on magnetism to select magnetic substances from garbage to achieve the purpose of purifying and recycling organic matter.
Specification:
Items | TT-DH50 | TT-DH80 | TT-DH100 | TT-DH200 | TT-DH300 | TT-DH500 | TT-DH800 |
Raw materials | Urban garbage, domestic garbage, household garbage, municipal garbage, etc., such as: kitchen garbage, video garbage, plastic garbage, solid garbage, paper, etc. | ||||||
Capacity T/D | 50 | 80 | 100 | 200 | 300 | 500 | 800 |
Power/kw | 80 | 92 | 120 | 132 | 180 | 230 | 287 |
Land area /㎡ | 600 | 850 | 1200 | 1650 | 2250 | 2500 | 3200 |
Workers required | 3 | 6 | 10 | 12 | 13 | 15 | 18 |
