4-35B Hopper Block Molding Machine Small And Medium Sized Permeable Brick
Product Details:
| Place of Origin: | China |
| Brand Name: | TONTEN |
| Model Number: | DF4-35B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wood case packing or customized |
| Delivery Time: | 10 days |
| Payment Terms: | T/T |
| Supply Ability: | 2 sets about 10 days |
|
Detail Information |
|||
| Port: | QingDao/ShangHai/TianJin | Advantage: | Fully Automatic |
|---|---|---|---|
| Raw Material: | Clay/Cement/Concrete | Mold Cycle: | 35S |
| Machinery Test Report: | Provided | Warranty: | 1 Year |
| Dimension: | 1200mm X 1280mm X 1950mm | Key Selling Points: | Easy To Operate |
| Highlight: | Permeable Brick Molding Machine,Medium Sized Permeable Brick Molding Machine |
||
Product Description
4-35B Hopper Block Molding Machine Small And Medium-sized Permeable Brick
Block molding machine with hopper is an automated equipment used to produce building blocks, which can also be said to be a small brick production line, by realizing the operation of the production line under the joint action of mixer, conveyor belt and hopper. It can be widely used in building block industry. A variety of raw materials is very wide: River sand, construction waste, cement, concrete, pebbles, slag, fly ash, copper slag, sand and so on.
4-35B Hopper Block Molding Machine Main Structure
Hopper: It is used for storing and conveying raw materials, and can be used with flat mouth mixer, which is more convenient and quicker.
Forming mold: It can decide the shape and size of the blocks, and the molds are diversified and replaceable.
Hydraulic system: Provide high pressure power to ensure the blocks are molded tightly.
Control system: PLC control system is adopted to realize automatic operation.
Conveyor belt: Used to convey the molded blocks.
Hopper Block Molding Machine
| Molding cycle | 35s |
| Equipped power | 6.3kw |
| Class production |
20000 pieces standard brick 240*53*115mm |
| Plate size | 850*550*30mm |
| Weight | 830kg |
| Operators | 2-3 people |
Hopper Block Molding Machine
Hopper Block Molding Machine Features
① Hopper design:
Equipped with large-capacity hopper, it can hold a large amount of raw materials such as concrete cement, sand, gravel and water, which can realize the idea of continuous operation.
② Automatic mixing:
A flat mixer can be connected to mix the raw materials, and the hopper can automatically mix the materials before feeding them into the mold.
③ Hydraulic system:
Block molding is performed using hydraulics to obtain high density and strength of bricks.
④ Interchangeable molds:
Equipped with a variety of molds to produce different sizes and types of blocks, such as hollow blocks, solid blocks and interlocking paving bricks, to meet the needs of different customers.
⑤ User-friendly control unit:
PLC control panel, easy to use, for operating the machine and adjusting the settings are very simple.
Frequently Asked Questions
1. What is the quality of the machine?
Our machines utilize advanced technology. In addition, we strictly supervise the production process to ensure the high quality of each finished product.
2. About the delivery time.
Usually, it will take about 10-15 working days after receiving your deposit, which will also depend on your order. 3.
3. About warranty.
We provide 12 months warranty.
4. Which payment method can we use?
T / T payment is 30% in advance and 70% of the balance before T / T shipment. You can also choose other transaction methods.
